New Style Surgical Instrument Patient Monitor Price

Quantity:
Inquire Add to Basket

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • HM-8

  • Patient/Fetal/Maternal Monitor

  • All

  • Ysyjxzz20132210751

  • 7 Inch High Resolution Color TFT LCD Display

  • 12months

  • Measuring Method

  • Bandwidth 0.1~2.5Hz Resp

  • Resolution 1%

  • Carton

  • Jiangsu, China

  • Physiological Functions of Diagnosis and Monitoring Equipment

  • CE, ISO13485

  • Type 2

  • ECG, NIBP, SpO2, Resp

  • ISO, Ce

  • IBP

  • Ra-Ll Impedance

  • Range 0~100%

  • Healicom

  • CE, ISO

  • 9018909090

Product Description

Specifications
8" inch high-resolution color screen
ECG, NIBP, SpO2, RESP ,TEMP,PR
Capture dynamic waveforms

The display is 8 inch high resolution color TFT.
It is equipped with 6 parameters including ECG, NIBP, SpO2, RESP , TEMP, PR. These four parameters can be flexible.
You can choose different combinations as you need.
This monitor is built-in rechargeable lithium battery.
The working capacity is 5 hours.

Specification:

ECG



*lead mode;I,II,III,AVR,AVL,AVF,V
*Gain:X0.25,X0.5,X1,X2
*Heart Rate:15-300BPM(Adult) 15-350BPM(Neonatal)
Resolution:1 BPM
Accuracy:+-1%
* ST measurement Range:-2.0-+2.0mV
Accuracy:+-10%
*Pacemaker:Yes
*Sweep Speed:12.5 mm/s,25mm/s,50mm/s
*Bandwidth:Diagnostic:0.05--130Hz
Monitor: 0.5--40Hz
Surgery: 1-20Hz


Spo2

*Measure Range:0-100%
*Resolution:1%
*Accuracy:2%(70-100%)
*Pulse Rate:20-250BPM
*Resolution:1BPM
*Accuracy:+-3BPM


NIBP

*Work mode:Manual,Automatic,Continuous
*Unit:mmHg,Kpa
*Measure Range:
Adult:
SYS: 40-280mmHg
DIA: 10-225mmHg
MEAN:20-240mmHg

Pediatric:
SYS:40-220mmHg
DIA: 10-160mmHg
MEAN:20-170mmHg

Neonatal:
SYS:40-135mmHg
DIA:10-100mmHg
MEAN:20-110mmHg
*Resolution:1mmHg
*Accuracy:+-5mmHg


RESP

*Measure Range:0-150BrPM
*Resolution:1BrPM
*Accuracy:+-2%
