HBW-3
Healicom
Product Description
Display modes | B, B/B, 4B, B+M, M |
Gray scale | 256 levels |
Dynamic range | 0~120dB adjustable |
External LED display | have 16 kinds of pseudo color |
Permanent storage | 128 images |
Capacity cine loop | real time display 256 consecutive images which are memorized successively |
Gain control | 8 segments TGC and overall gain can be adjusted respectively |
Frequency conversion | 2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0MHz five periods of frequency conversion; frequency range applies 5.5 MHz/6.0 MHz/6.5 MHz/7.0 MHz/7.5MHz can match high frequency probe |
Image multiplying factor | 3.5MHz/R60 convex array probe: ×0.8, ×1.0, ×1.2, × 1.5,×1 .8, ×2.0 (six modes)×0.8, ×1.0 (display penetration depth) |
E-zoom | magnify 2 times of real time image |
Focus position | dynamic electron focusing |
Output Interface
1 groups of USB video output 1 groups of SVGA video output may mate with SVGA color monitor. 1 groups of PAL video output may mate with PAL monitor, video image recording instrument and image workshop, etc
USB Port: our machine can connect the common printer. Used to print the measurement report page.
