HV-T50 Touch Screen Multi-mode Ventilation Function ICU Ventilator

The HV-T50 ICU Ventilator features a 12.1 inch touch screen with attractive color schemes and an intuitive interface for precise control and easy operation. Its high performance turbine ensures accurate flow output. With multi mode ventilation options for both invasive and non - invasive use, it caters to various patient needs. The ventilator also has self testing, calibration, and comprehensive monitoring with flashing alarms. Optional features include assistant nebulization, high flow oxygen therapy, and auxiliary suction.
Availability:
Quantity:

PDF Export

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
  • HV-T50

  • Healicom

Product Description

12.1 Inch Touch Screen Multi-mode Ventilation Function ICU Ventilator On Sale1

Feature

· 12.1 inch touch screen with desirable color schemes

· The simplest interface boots a precise control and convenient operation

· High performance turbine with precise control technology provides accurate flow output.

· Multi-mode ventilation function(VCV,SIMV, SIMV/PSV, PSV, PCV, APNEA, CPAP, BIPAP,Manual, SIGH)

· Applied with Invasive ventilation and Non-invasive ventilation

· Self testing and calibration function

· Comprehensive monitoring and alarm functions with flashing alarm indicator(Priority alarm, secondary alarm).

· Assistant Nebulization treatment, High flow oxygen Therapy Auxiliary suction function  (Optional)

2



Technique Specifications
Physical Specifications
Trolley  (Optional )
Dimensions
45*55*14CM
Weight
10.5Kg (Main unit)
Casters
Front wheels with lock
Screen
12.1 inch touch screen
Display
Colour LCD
Display graphics
Waveforms of P-T, F-T, V-T
Loops
P-V, F-V, F-P
Pipeline Supply
Gas configuration
O2
Pipeline input range
280-600KPa
Battery Power
Run-time
Typical 180 mins+
Ventilator Specifications
Modes of Ventilation
VCV
Volume control ventilation
APNEA
APNEA
SIMV
Synchronized Intermittent Mandatory Ventilation
SIMV/PSV
SIMV/Pressure support
MANUAL
Manual
CPAP
Continuous Positive Airway Pressure
PSV
Pressure Support Ventilation
PCV
Pressure Control Ventilation
NIV
Non-invasive ventilation
BIPAP
BIPAP
SIGH
SIGH
APRV
(Optional)
Ventilator Parameter
Tidal Volume range
20-2000ml
Pressure range
5-80 cmH2O
Respiration Rate Range
1-100bpm (1-40bpm under SIMV)
I:E Range
4:1-1:8
Oxygen concentration
21%-100%
Ptrigger Range
-20-0cmH2O
Apnea Ti Range
0-6s
PEEP
Type
Integrated, Electronic control
Range
0-40cmH2O
Alarm Limits
Visual
No tidal volume, MV, Paw, FiO2 limitation O2,Air failure, AC power failure, backup low
Audio
No tidal volume, MV, Paw, FiO2 limitation
Pre-setting Functions
Language
English
Calibration
AUTOMATIC
Optional
Auxiliary Suction function
O2 remedy
Communication port
RS-232, HDMI, Ethernet, USB *Optional*
Environmental Conditions
Operating Temp
5ºC ~40ºC
Storage Temp
-10ºC ~+40ºC
Humidity
<80%
Atmosphere pressure
960hPa ~ 1040 hPa
