HFX-08 Portable High Frequency 8KW X-ray Machine

It can be widely use for human limbs checking, diagnosing, especially used in hospital room, ambulance, disaster relief, emergency medical treatment, sports events, charity organizations, diagnosis etc.
Availability:
Quantity:

PDF Export

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
  • HFX-08

  • Healicom

Product Description

Features

1. High frequency inverter frequency conversion technology, energy saving and high efficiency;

2. Multi-mode control exposure, easy to operate;

3. Realize the functions of automatic debugging, automatic detection, automatic filament calibration, etc.;

4. With remote maintenance, remote software upgrade, remote intelligent management;

5. With exposure parameter return function

6. The expansion interface is rich, which is convenient for product upgrade and transformation;

7. The AED synchronization and external synchronization of the flat panel detector can be switched flexibly;

8. With a variety of error code sets, it is beneficial to accurately locate the fault point and improve the efficiency of investigation;

9. Compact structure, small size, light weight, easy to carry and move;


企业微信截图_16582132094645

Technial Specifications
Power
8kW
Voltage
AC220V ± 10%
kV Range
40~125kV
mA Range
5~160mA
mAs Range
0.1-200mAs
Working Frequency
100kHz
Exposure time
0.0032S~10S
Double Focus
2.0 mm
Head size
420mm * 245mm * 240mm
Head Weight
18KG
