HFX-05D
Healicom
Product Description
Features
1. Deft and concise
2. 6 periods of digital LED display
3. Failure self-protection, self-diagnosis
4. High precision control of tube voltage, tube current
5. 48 kinds of presupposed anatomy memory pattern choice
6. Accuracy control method of simulation and double digital loops
7. X-ray tube complete surrender by lead for protect X-ray leaking
Complete software performance and Connection
Profession Acquisition Software
Support different brand of X-ray generators
Support Multi- languages
Support RIS/PACS/DICOM Printer Connection
Support professional tools
Professional and efficient DR workstation
Patient management
Image capture
Image post-processing
Print and storage
| Technical Specifications | ||
| | Voltage | AC220V ± 22V |
| Power | 5kW | |
| kV Range | 40~110kV | |
| mA Range | 20~100mA | |
| mAs Range | 0.2-200mAs | |
| Working Frequency | ≥40kHz | |
| Exposure time | 0.01S~4S | |
| Anode heat storage | 56KHU | |
| | Focus | 1.8mm |
| Inherent filtration | 1mm Al/75Kv | |
| Collimator | Light source | LED |
| | Dimension | 10.4inch |
| Scintillator | CsI | |
| 17*17inch | Pixel Pitch | 139 |
| Limit resolution | 3.6 | |
| Pixels | 3072*3072 | |
| | CPU | Intel Core i5 |
| Memory capacity | 4GB | |
