Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp

Quantity:

PDF Export

  • HLED-M5/5
  • Surgery
  • All People
  • Double Operating Light
  • Ssyjxz20142540817
  • Ra>95
  • CREE XPE-Q3
  • 700mm
  • 40~120klx
  • Advanced Digital Imaging Technology
  • Wooden Case
  • Jiangsu, China
  • Operating Light
  • CE, ISO13485
  • Without LCD Display
  • Type 2
  • Ce ISO
  • Ec<1000W/M2
  • 550mm
  • 12 Months
  • China
  • healicom
  • CE ISO
  • 9405409000

Product Description

Introduction
HLED series operating lamp is suitable for all kinds of operations. It is an ideal lighting technical equipment for modern operating room and purification operating room.
1. Ideal cold light effects. Imported LED cold light source for lighting devices as surgery. Doctors head and wound will have no temperature rise.
2. Reliability of circuit design. Digitally regulated LED brightness, wide range of uniform brightness, adjust and flicker-free.
3. Extremely long service life of light source. LED lamp life of up to 50,000 hours, each LED can be replaced individually, which guarantees maximum economy.
4. Ideal for meeting the requirements of clean appearance. Streamlined design meets the requirements of modernization in laminar flow operation room.
5. Advanced digital imaging technology.

SPECIFICATION
Model HLED M7 main lamp JHLED M5 main lamp
Reflector diameter 750mm 550mm
Center illuminance 40~160klx 40~120klx
Spot diameter(d10) 230mm 150mm
Spot diameter(d50) 160mm 120mm
Light beam depth 700mm 700mm
Color temperature 4200±300k 4200±300k
Color rendering index Ra>95 Ra>95
Maximum illuminance Ec<1000W/m2 Ec<1000W/m2
Light source LED(1W×152) LED(1W×88)
The model of LED CREE XPE-Q3
Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp Surgical Use Hled-M5/5 LED Shadowless Operating Lamp Operating Room Lamp
