HX50R-A
Healicom
Product Description
1. Rich DR upgrade reserve interface
2. Fault self-diagnosis and protection
3. Automatic calibration of tube current
4. X-ray tube has the function of filament dormancy
5. AEC function, different ionization chamber as optional
6. Analog - digital double - loop control, simple operation, high intelligence
7. High kV, high current, high power,strong penetration,able to handle obese patients
| Technical Specifications | |
| X-ray generator (include console) | |
| Output Power | 50KW |
| Power Voltage | 380V±38V |
| kV range | 40~150kV |
| mA range | 10~630mA |
| mAs range | 0.1 ~630mAs |
| Exposure time | 0.002~6.3S |
| X-ray tube | |
| Anode Heat Storage Capacity | 240kHU |
| Small focus | 0.6 |
| Large focus | 1.2 |
| Anode speed | 3000r/min |
| Collimator | |
| Inherent filtration | 1.0mm Al /75kV |
| Light Source | LED |
| Radiographic Table | |
| Top Table Size | 2100X800X650mm |
| Bucky Size | 18X18inch |
| Table longitudinal movement | ≥900mm |
| Cassette Movement Distance | ≥500mm |
| Vertical Chest stand | |
| Vertical moving range | ≥1200mm |
| Bucky Size | 18X18inch |
| Double Grid | |
| Size | 18X18inch |
| Ratio | 1:1 |
| F.D. | 100cm |
| Density | 40 L/cm |
