HS-C
Healicom
Product Description
• Automatically controlled the sterilizing process, easy to operate.
• With drying function, suitable for the medical dressing drying.
• With overtemperature, overpressure autoprotective.
• The door can not be open until the pressure in the chamber is reduced to 0.027MPa. And the unit can not be started on if the Indoor doesn't close well.
• The safety valve will be open automatically when the inner pressure over 0.24MPa and the steam would be exhausted the water tank.
• Automatically cut off the power if the water lack happened, and alarm at the meanwhile.
• Fully stainless-steel structure.
Technical Specifications | |||
Model | HS-150C | HS-200C | HS-280C |
Sterilizing chamber volume | 150L φ440×1000 | 200L φ515×1000 | 280L φ600×1000 |
Working pressure | 0.22Mpa | ||
Working temperature | 134℃ | ||
Temperature adjust range | 134℃ | ||
Time for sterilization | 0-60min | ||
Time for drying | 0-60min | ||
Heat average | ≤±2℃ | ||
Power | 9kw/380V 50Hz | 9kw/380V 50Hz | 12kw/380V 50Hz |
Dimension | 1400×600×1300 | 1400×670×1650 | 1400×770×1780 |
Exterior package dimension(mm) | 1550×750×1850 | 1560×820×1850 | 1680×920×2100 |
G.W/N.W | 320/240kg | 350/260kg | 465/365Kg |
