HFX-32D Medical Equipment Digital 32KW Mobile X Ray Machine

The HFX-32D mobile DR system is a compact and lightweight imaging solution designed for exceptional portability, enabling it to reach any location within a healthcare facility. Its small size and ease of maneuverability make it ideal for use in challenging environments, particularly in isolated wards, ICUs, emergency rooms, and isolation areas. The system is specifically tailored for intensive bedside imaging, allowing clinicians to perform high-quality diagnostic exams without the need to move critically ill or contagious patients. This minimizes patient discomfort and reduces the risk of complications associated with transportation. With its advanced imaging capabilities and user-friendly design, the HFX-32D ensures efficient and accurate diagnostics, enhancing patient care in high-stakes medical settings.
Availability:
Quantity:

PDF Export

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
  • HFX-32D

  • Healicom

Product Description

HFX-32D Medical Digital Mobile DR  X Ray Machine

1


HFX-32D The mobile DR is small in size&light in weight, and the device can reachany place where it is needed. It is suitable for isolating the ward, especially the ICU, Emergency, Isolation area intensive bedside filming to avoid patient movement.

Technical Specifications
Power
32kW
Voltage
AC220V/110V ± 10%
kV Range
40~125kV
mA Range
10~400mA
mAs Range
0.32~400mAs
Working Frequency
≥100kHz
Exposure time
0.002S~6.3S
Focus
1 mm / 2 mm

2


4

6
