Animal Equipment WTK-400 Vet High Accuracy Different Infusion Mode Large Colorful LCD Screen Infusion Syringe Pump Machine

Availability:
Quantity:

PDF Export

  • WTK-400
  • Healicom

Product Description

Animal Equipment WTK-400 Vet High Accuracy Different Infusion Mode Infusion Syringe Pump Machine


Feature
1.History records
2.Unique intelligent self-recognition technology of syringes
3.KVO, Bolus and Anti-bolus
4.Applicable for 5, 10, 20, 30, 50(60)ml syringes
5.Compatible for various brands of syringes
6.Vanous infusion modes to meet different clinical requirements
7.Various visual and audible alarms
8.Numeric keys design, easy to operate
9.Large colorful LCD screen
10.Real time display, ensure the infusion information to be recorded correctly
11.3 adjustable occlusion levels, dynamically display the pressure
12.Night mode
13. Doube CPU ensuring safe infusion


Specification



 Infusion mode

 Rate mode

 Time mode

 Body weight mode

 Intermittent infusion mode(Optional)

 Drug library mode(Optional)

 Applicable Syringe

 Various brands of sterile syringes: 5ml, 10ml, 20ml, 30ml, 502ml/60ml

 Accuracy

 ±2% (After syringe correct calibration)

 Infusion rate

 5ml syringe:0.1-150ml/h

 10ml syringe:0.1-300ml/h

 20ml syringe:0.1-600ml/h

 30ml syringe:0.1-900ml/h

 50ml (60ml) syringe:0.1-1500ml/h

 Volume to be infused (VTBI)

 0-1000ml

 Volume infused

 0-9999.9ml

 KVO rate

 0.1-2ml/h adjustable; default value 0. 1ml/h

 BOLUS (ml/h)

 5ml syringe: 100-150ml/h

 10ml syringe: 100-300ml/h

 20ml syringe: 100-600ml/h

 30ml syringe: 100-900ml/h

 50ml (60ml) syringe: 100-1500ml/h

 History record

 1600 records

 Computer interface

 RS232 interface

 Alarm

 Syringe disengaged, Almost done, infusion completion, Empty, Occlusion, Low battery, handie off, AC fail, On Battery, Battery exhausted etc.

 Power supply

 DC:12±1.2VAC:100-240V,50/60HZ

 Power consumption

 25VA

 Nurse call interface

 Optional

 Wireless monitoring system

 Optional

 Classification

 Class I, type CF

 Dimension

 300*130*125mm( L*W*H)

 Net Weight

 1.8KG
