High Quality WET-9000A Medical veterinary small animal video endoscope

Availability:
Quantity:

PDF Export

  • WET-9000A
  • Healicom

Product Description

Products Description
Specification


1.parameter of endoscope
1-1
Top diameter
≤Φ8.0mm
1-2
Input tube
≤Φ8.0mm
1-3
Biopsy channel
≥Φ2.0mm
1-4
Working length
≥1500mm
1-5
Total length
≥1800mm
1-6
Field of view
≥140º
1-7
Depth of field
≥3-100mm
1-8
Image solution
≥480000pixels (CCD)
1-9
Bending angles
≥ up210º down≥90º left&right≥100º maximum 230°
1-10
Image frozen
4 images frozen,stroe,playback.
1-11
warranty
One year


2.parameter of processer& light source
2-1
Contrast adjustment
0-128
2-2
Image adjustment
color adjustment level: 0-128,vessel enhancement
2-3
Metering mode
AVE/PEAK
2-4
Image enhance
0-30
2-5
White balance
Auto/manual white balance
2-6
Pump
pressure 30-80Mpk,air supply 4L/min-10L/min
2-7
illuminance
≥200000Lx,LED light source 30000hours life.


3.parameter of suction device
3-1
Vessel capacity
Not less than 1 l
3-2
Maximum suction volume
20 L / Min


4.parts list WET-9000A
product name
Quantity
Remark
VET-9000A video Endoscope
VET-9000A video Endoscope
1

Biopsy forceps
6
Different type
Cleaning brush
1

Mouth pad
3

Leak detector
1

Leak cover
1

Clean lid
1

Attract the valve body baffle cap
2

Water bottle interface seal ring
6

Wash ear ball
1

Water injection bottle assembly
1

Endoscopic box
1

Instructions
1

EMV-3000 Endoscope processor &light source (With air pump and Rigid endoscope interface)
EMV-3000 Endoscope processor &light source(LED lamp)
1

power cable
1

Instructions
1

Suction device
Suction device
1

power cable
1

Instructions
1

Trolly
1

19” LCD monitor
1
