8mA Medical Dental X-ray with Chair (HC-10D)
You are here: Home » Products » Dental equipments » Dental X-ray » 8mA Medical Dental X-ray with Chair (HC-10D)

Category List

8mA Medical Dental X-ray with Chair (HC-10D)


PDF Export

  • HC-10D
  • 60kvp
  • 1.5mm
  • 0.2 - 4sec
  • Healicom
  • China
  • AC 220V±10%, 50Hz, 1kVA
  • 8mA
  • 2.5mmal
  • X-Ray Equipment
  • ISO
  • 90221300

Product Description

HC-10D Dental X-ray Unit

Product Description
1. The microprocessor-controlled timer brings high-tech X-ray imaging at your fingertips.
2. The control panel allows an accurate and fast exposure time selection while protecting the head during X-ray examinations.
3. Fitted with 70KV 8mA tube with preheating grid, the machine has been specially designed for intraoral dental diagnosis applications.

4. Complies with local and international regulations on ionizing radiation protection for maximum safety.
5. The soft position arm ensures naturally smooth and well-balanced movements. It is easy installed at the desired height and length.

6. Its ergonomics and design have been studied to meet the requirements of the most demanding practices in matters of floor space optimization

Power supply AC 220V±10%, 50Hz,1KVA
Tube voltage 60kVp
Tube current 8mA
Focus size 1.5mm
Total filtration 2.5mmAL
Exposure time 0.2 - 4sec
Leak radiation Outside one meter ≤ 0.002mGy/h
Optional: Tube current: 0.5mA Focus size: 0.8mm
Package Pack Size(MM) Weight(Kg)
wooden case 1450*600*330 49(Net:40)
800*700*180 27(Net:20)

8mA Medical Dental X-ray with Chair (HC-10D)
8mA Medical Dental X-ray with Chair (HC-10D)
8mA Medical Dental X-ray with Chair (HC-10D)
