HA-PC
Healicom
Product Description
· Portable design, easy to operate and save space in operation theatre.
· Molding Production with a benefit of light weight and rust-proof.
· Integrated breathing circuit design ensures simple operation and clear equipment.0.8L CO2 absorber also equipped on breathing circuit.
· APL valve design can set the pressure limit under manual control.
· 4 tubes flow meter for O and N2O, support low flow anesthesia.
· Self-designed high precision Vaporizer with flow, pressure, temperature compensation, self-locking structure.High precision of anesthesia agent control.
Technique Specifications | |
Physical Specifications | |
Dimensions | 50*46*32 |
Weight | 22kg |
Casters | Front wheels with lock |
Pipeline Supply | |
Gas configuration | O2, N2O |
Pipeline input range | 280-600Kpa |
Modes of Ventilation | |
MANUAL | Manual |
Ventilator Parameter | |
Working type | Pneumatic driven |
System Standard | |
Hypoxic guard system | N2O cut-off valve, O2 concentration >25% |
APL valve | <6kPa |
O2 Flush | 25-75L/min |
volume of co2 absorber | 0.8 L(Optional for 1.6L co2 absorber) |
Flow meter | 4 tubes, Cascade 0.1-10L/min Oz,0.1-10L/min N2O |
Vaporizer | 1 unit,(isoflurane/Enflurane Sevoflurane/Halothane) |
Optional | |
Anesthesia ventilator (cWH-1010,1020) | |
Trolley | |
AGSS |
