Features
• Standard integrated metallic modular respiratory circuit; completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect
• High precision two tube flowmeter, fitted with interlocking oxygen-nitrous oxide supply, guarantees oxygen output is never lower than 21%
• Power Failure Support Functions: Automatically converts to backup power mode during AC power outages
• Alarms: Audible and/or visual alarms for tidal volume, airway pressure, power failure, oxygen failure and other alarms
• Equipped with infrared turbine flow sensor; precisely measures gas flows, stable and reliable
• Vaporizer: Imported tank components assembled locally; Also possesses self-compensating functionality
• Equipped with advanced international rotating Na-lime tank, easy-operate, requires only one hand, and uses imported PPSU material and temperature resistant to 134°C
Advanced Model Exclusive Features
• Vaporizer with dual tank design, effective for extending surgical lengths and features interlocking tank capability
| Physical Specifications | |
| Screen | LED Display Screen |
| Suitable | Adult & Child |
| Mode | pneumatically powered and electrically controlled system |
| Working Mode | Closed; Semi-Closed; Semi-Open |
| Circuit | Breathing circuit integrated standards |
| Tube | 2 Tubes Flowmeters: O2:0.1~10L/Min, N2O:0.1~10L/Min |
| Trolley | Fitted with 4 nos anti-static rubber castors; two of which are lockable for braking and easy maneuverability with foot operated brake provisions |
| Safty | NO2 Automaticlly Cutting while oxygen deficiency |
| Drawer unit | ONE drawer totally extractable |
| Technical Specifications | |
| Gas requirement | Medical oxygen and nitrous oxide with a pressure ranging from O2: 0.32~0.6MPa ; NO2: 0.32 MPa to 0.6 MPa. |
| safety valve | <12.5 kPa |
| Respiratory Rate | 4~40bpm |
| Flow meter | O2:0.1~10L/Min, N2O:0.1~10L/Min |
| Oxygen concentration in the mixed gas N2O/O2 | > 21% |
| Oxygen Flush | 25~75 L/min |
| Maximum error of the pressure testing device | not exceed ± (4% of the full scale reading + 8% of the actual reading) |
| Modes of ventilation | A/C, IPPV, SIPPV, MANUAL |
| I/E Ratio: | 1:1.5; 1:2.0;1:2.5; 1:3 |
| Tidal Volume | 0~1500ML |
| Controlled ventilation and assisted ventilation switching time | 6s |
| Maximum safety pressure | ≤ 12.5 kPa |
| Pressure limit range | 0 ~ 6.0 kPa |
| Airway pressure alarm: Audible and visual and with yellow and red color indicating | Lower: 0.2kPa~5.0kPa; Upper: 0.3~6.0 kPa (±0.2 kPa) |
| Tidal volume alarm: Audible and visual and with yellow and red color indicating | upper alarm: 50 to 2000ml,lower alarm: 0~1800ml |
| Power Supply Alarm | Ac/dc power supply are after failing to send out alarm immediately Alarm Time: keep >120s |
| Configuration | |
| Vaporizer | Enflurane/ Isoflurane(Option: Halothane) |
