· Portable design, easy to operate and save space in operation theatre.
· Molding Production with a benefit of light weight and rust-proof.
· Integrated breathing circuit design ensures simple operation and clear equipment.0.8L CO2 absorber also equipped on breathing circuit.
· APL valve design can set the pressure limit under manual control.
· 4 tubes flow meter for O and N2O, support low flow anesthesia.
· Self-designed high precision Vaporizer with flow, pressure, temperature compensation, self-locking structure.High precision of anesthesia agent control.
| Technique Specifications | |
| Physical Specifications | |
| Dimensions | 50*46*32 |
| Weight | 22kg |
| Casters | Front wheels with lock |
| Pipeline Supply | |
| Gas configuration | O2, N2O |
| Pipeline input range | 280-600Kpa |
| Modes of Ventilation | |
| MANUAL | Manual |
| Ventilator Parameter | |
| Working type | Pneumatic driven |
| System Standard | |
| Hypoxic guard system | N2O cut-off valve, O2 concentration >25% |
| APL valve | <6kPa |
| O2 Flush | 25-75L/min |
| volume of co2 absorber | 0.8 L(Optional for 1.6L co2 absorber) |
| Flow meter | 4 tubes, Cascade 0.1-10L/min Oz，0.1-10L/min N2O |
| Vaporizer | 1 unit,(isoflurane/Enflurane Sevoflurane/Halothane) |
| Optional | |
| Anesthesia ventilator (cWH-1010,1020) | |
| Trolley | |
| AGSS | |
